                    Barrier Terminal Block KF-30RM-8.25mm
                    Material:M3.0 Steel,Ni platedTerminal:Brass,0.8t Ni platedHousing: PA66,UL94V-0ElectricalULIECRated voltage300V 450V Rated current20A24AInsulation resistance500MΩ/DC500VWithstanding voltage AC2000V/1minWire range22-12AWG 2.5mm2MechanlicalTemp.rang-40℃~+105℃ Torque0.5N.m 4.4Lb.in
                    Color
                    • Kaifeng Electron
                    Line count
                    • 02P
                    • 03P
                    • 04P
                    • 05P
                    • 06P
                    • 07P
                    • 08P
                    • 09P
                    • 10P
                    • 11P
                    • 12P
                    • 13P
                    • 14P
                    • 15P
                    • 16P
                    • 17P
                    • 18P
                    • 19P
                    • 20P
                    • 21P
                    • 22P
                    • 23P
                    • 24P
                    Kaifeng Electron Kaifeng Electron
                    Consult more
                    Kaifeng Electron Kaifeng Electron
                    Product Parameters
                    Kaifeng Electron Kaifeng Electron
                    Product Drawing
                    Product Drawing Material Electrical Mechanical Packaging
                    Product Drawing
                    Kaifeng Electron
                    Material
                    • Screws
                      M3.0 Steel Zinc plated
                    • Terminal
                      Brass,0.8Tin Plated
                    • Housing
                      PA66, UL94V- 0
                    Electrical
                    • Rated voltage
                      300V UL丨 450V lEC
                    • Rated current
                      20A UL丨 24A lEC
                    • Insulation resistance
                      500MΩ/DC500V
                    • Withstanding voltage
                      AC2000V/1Min
                    • Wire range
                      22-12AWG 2.5mm2
                    Mechanical
                    • Temp.rang
                      LOW-40℃ 丨TOP+105℃
                    • Torque
                      0.5N.m 4.4Lb.in
                    Packaging
                    • Net Weight
                      xg
                    • SPQ
                      12pcs
                    • Packaging
                      Ziploc
                    • MOQ
                      12pcs
                    • Packaging
                      Box45cm*28cm*27cm
